GIGABYTE B760M GAMING X DDR4 mATX Motherboard
In stock
Short Description
- Model: B760M GAMING X DDR4
- Supported CPU: 14th/13th/12th Gen Intel Processors (LGA1700)
- Supported RAM: 4x DDR4, Max 128GB 5333(OC)
- Graphics Output: 1x HDMI, 1x DisplayPort
- Features: Realtek 2.5GbE LAN chip
20,400৳ 22,570৳
In stock
GIGABYTE B760M GAMING X DDR4 mATX Motherboard
The GIGABYTE B760M GAMING X DDR4 mATX motherboard is a high-performance designed for Intel 13th and 12th Gen processors with LGA1700 socket support, making it ideal for gaming enthusiasts and power users. Equipped with an advanced 8+1+1 phase Hybrid Digital VRM, it ensures stable and efficient power delivery to the CPU, even during intense gaming sessions or heavy multitasking.
This motherboard supports Dual Channel DDR4 memory across 4 DIMM slots, allowing for memory speeds that enhance system performance. For next-gen storage, the GIGABYTE B760M GAMING X DDR4 offers two PCIe 4.0 x4 M.2 connectors, delivering ultra-fast data transfer rates for NVMe SSDs. The M.2 Thermal Guard ensures your SSDs stay cool and maintain optimal performance, while the enhanced thermal design guarantees consistent VRM stability.
Designed with gamers in mind, the GIGABYTE B760M GAMING X DDR4 features an EZ-Latch PCIe 4.0 x16 slot with a quick-release design for easy installation or upgrading of your graphics card. The motherboard also includes a fast 2.5GbE LAN for reliable high-speed internet connectivity, perfect for online gaming and streaming.
Connectivity options are plentiful, with front-panel USB-C 10Gb/s for fast data transfer, along with DisplayPort (DP) and HDMI outputs for flexible multi-display setups. The Smart Fan 6 technology offers advanced cooling control, featuring multiple temperature sensors and hybrid fan headers with FAN STOP to ensure quiet operation and effective cooling.
Additionally, the Q-Flash Plus feature simplifies BIOS updates, allowing you to upgrade without needing to install the CPU, memory, or graphics card.
Key Features:
- Supports Intel 13th and 12th Gen processors (LGA1700)
- 8+1+1 phase Hybrid Digital VRM for stable power delivery
- Dual Channel DDR4 with 4 DIMM slots
- 2 PCIe 4.0 x4 M.2 connectors with M.2 Thermal Guard
- EZ-Latch PCIe 4.0 x16 slot for quick GPU installation
- 2.5GbE LAN for fast, reliable network performance
- Front USB-C 10Gb/s, DisplayPort, and HDMI for versatile connectivity
- Smart Fan 6 with FAN STOP for advanced cooling
- Q-Flash Plus for easy BIOS updates without CPU, memory, or GPU installation
With powerful performance, enhanced cooling, and cutting-edge connectivity, the GIGABYTE B760M GAMING X DDR4 is a perfect choice for gamers and creators seeking a reliable and efficient motherboard solution.
What is the price of GIGABYTE B760M GAMING X DDR4 mATX Motherboard in Bangladesh?
Lastly, You can buy this product from Best Computer Hub Ltd. The latest GIGABYTE B760M GAMING X DDR4 mATX Motherboard in Bangladesh is 20,500৳.
Order Online Or Visit your Nearest Best Computer Hub Shop to get yours at lowest price.
| Basic Information | ||
| Supported CPU | LGA1700 socket: Support for the 14th 13th and 12th Generation Intel Core, Pentium Gold and Celeron Processors L3 cache varies with the CPU |
|
| Chipset | Intel B760 Express Chipset | |
| BIOS | 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
|
| Form Factor | Micro ATX Form Factor; 24.4cm x 24.4cm | |
| Audio | Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out |
|
| Expansion Slots | ||
| PCI | 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16) 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4) |
|
| M.2 Socket | 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB) 4 x SATA 6Gb/s connectors |
|
| Memory | ||
| Type | DDR4 | |
| Slots | 4 | |
| Supported Memory | Support for DDR4 5333(O.C.)/ 5133(O.C.)/ 5000(O.C.)/ 4933(O.C.)/ 4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/ 4266(O.C.)/ 4133(O.C.)/ 4000(O.C.)/ 3866(O.C.)/ 3800(O.C.)/ 3733(O.C.)/ 3666(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3400(O.C.)/ 3333(O.C.)/ 3300(O.C.)/ 3200/ 3000/ 2933/ 2666/ 2400/ 2133 MT/s memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules |
|
| Maximum Memory | 128GB | |
| Graphics | ||
| Graphics | Integrated Graphics Processor-Intel HD Graphics support: 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz 1 x DisplayPort, supporting a maximum resolution of 4096×2304@60 Hz |
|
| Connector & Ports | ||
| HDMI | 1x HDMI | |
| Display Port (s) | 1x DisplayPort | |
| USB (s) | 1 x USB Type-C port with USB 3.2 Gen 2 support, available through the internal USB header 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header) 1 x USB 2.0/1.1 port on the back panel 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers) |
|
| LAN Port (s) | Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) 1 x RJ-45 port |
|
| Supported Storage | 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB) 4 x SATA 6Gb/s connectors |
|
| RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices | |
| Audio | 1 x front panel audio header 3 x audio jacks |
|
| Internal I/O Ports | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 3 x system fan headers 2 x addressable LED strip headers 2 x RGB LED strip headers 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB Type-C header, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 2 x Thunderbolt add-in card connectors 1 x serial port header 1 x reset button 1 x Q-Flash Plus button 1 x reset jumper 1 x Clear CMOS jumper |
|
| TPM (Trusted Platform Module ) | 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) | |
| Others | ||
| Special Features | 2 x addressable LED strip headers 2 x RGB LED strip headers iTE I/O Controller Chip Support for GIGABYTE Control Center (GCC) Support for Q-Flash Support for Q-Flash Plus |
|
| Warranty Information | ||
| Manufacturing Warranty | 3 years | |
