HPE Aruba Networking 580EX Series Hazardous Location Access Points


Short Description

  • Certifications Wi-Fi Alliance
  • Bluetooth SIG
  • Ethernet Alliance (E0, PoE PD device, Class 6; E2, PoE PSE device, Class 3)
  • Class 1 Div 2
  • ATEX Zone 2
  • IECEx

HPE Aruba Networking 580EX Series Hazardous Location Access Points Deliver Rugged Wi-Fi 6 for Extreme Environments

HPE Aruba Networking 580EX Series Hazardous Location Access Points are purpose-built to deliver reliable Wi-Fi 6 connectivity for hazardous outdoor locations such as oil rigs, industrial manufacturing, and transportation sites. With a maximum aggregate data rate of 2.97 Gbps, integrated high-power Bluetooth and 802.15.4/Zigbee radios, and industrial-grade surge protection, the 580EX Series ensures secure, high-performance wireless networking in the most challenging Industrial IoT deployments.

High-Performance Ruggedized Outdoor Wi-Fi 6 Access Points

Designed for Hazardous Industrial Deployments

HPE Aruba Networking 580EX Series Hazardous Location Access Points are engineered to withstand the most demanding outdoor and hazardous environments, delivering up to 2.97 Gbps maximum aggregate data rate for high-speed, low-latency connectivity. With Wi-Fi 6 certification and support for advanced wireless technologies, these APs are ideal for industrial manufacturing, energy production, transportation, and other mission-critical applications where network reliability is non-negotiable. Built-in options for 5G Ethernet, SFP+, and Power Sourcing Equipment (PSE) out provide flexible connectivity and simplify deployment in diverse network topologies.

Advanced Wi-Fi 6 Features

To maximize performance and improve efficiency, the HPE Aruba Networking 580EX Series integrates Wi-Fi 6 technologies such as Orthogonal Frequency-Division Multiple Access (OFDMA) for simultaneous transmissions to multiple devices, bidirectional MU-MIMO for higher throughput, and Target Wake Time (TWT) to reduce power consumption on connected IoT devices. Enhanced security with WPA3 encryption and Enhanced Open ensures stronger protection for enterprise traffic and guest access, while industrial surge protection keeps the APs safeguarded from electrical hazards.

Enhanced Wireless Experience

ClientMatch technology helps eliminate sticky client issues by dynamically steering devices to the access point with the best available signal, maintaining consistent performance across large outdoor areas. Dual redundant power and port failover capabilities ensure uninterrupted operation even if one connection fails, supporting high availability in critical environments. Whether supporting worker communications, IoT sensors, or mobile devices, the 580EX Series delivers dependable connectivity that keeps operations running smoothly.

Weatherproof and Temperature Hardened for Extreme Conditions

Certified for Hazardous Locations

The HPE Aruba Networking 580EX Series meets stringent safety and environmental standards with Class 1, Division 2, and ATEX Zone 2 certifications, making it compliant for use in locations with explosive gases, vapors, and dust. Purpose-built to survive in outdoor oil fields, chemical plants, and heavy industrial settings, these APs are fully sealed to keep out airborne contaminants and moisture.

Extreme Temperature Resilience

Tested and rated to operate in temperatures ranging from -40°C to +65°C, including full sun deployments, the 580EX Series thrives in both extreme heat and bitter cold. The IP66 rating ensures robust weatherproofing against persistent precipitation, wind-driven dust, and environmental exposure. Industrial-grade surge protection protects the devices against electrical damage, reducing the risk of downtime caused by unpredictable power events.

Flexible Deployment and Management

Zero Touch Provisioning and Simplified Setup

The HPE Aruba Networking 580EX Series streamlines deployment with Zero Touch Provisioning, enabling IT teams to configure and bring APs online remotely without requiring on-site technical support. Existing mounting hardware can be reused to further simplify installation and minimize disruption during upgrades or expansions.

Unified Cloud Management with Aruba Central

HPE Aruba Networking 580EX Central provides a single pane of glass to monitor and manage the 580EX Series and all network infrastructure components across wired and wireless LANs, WANs, and VPNs. AI-powered analytics, end-to-end orchestration, and automated workflows help IT teams optimize performance, quickly troubleshoot issues, and maintain continuous visibility into network health. Aruba Central’s policy enforcement and security tools simplify compliance and help protect sensitive data across the enterprise.

Enterprise-Grade Security and IoT Connectivity

Advanced Security Controls

Dynamic Segmentation automatically assigns policies to users and devices, removing the complexity of managing static VLANs and ACLs while keeping traffic protected and separated. Policy Enforcement Firewall (PEF) encapsulates and inspects all data from the access point to the gateway for end-to-end encryption and compliance. WPA3 and Enhanced Open provide stronger wireless authentication and encryption, while a Trusted Platform Module (TPM) securely stores credentials, encryption keys, and boot code to ensure device integrity.

Integrated IoT Radios

With built-in high-power Bluetooth 5 and 802.15.4/Zigbee radios, the HPE Aruba Networking 580EX Series extends secure IoT connectivity to industrial sensors, location tracking systems, and wireless controllers without requiring additional overlay networks. This flexibility enables organizations to deploy Industrial IoT solutions with confidence, improving operational visibility and efficiency in hazardous environments.

What is the price of HPE Aruba Networking 580EX Series Hazardous Location Access Points in Bangladesh?

Lastly, You can buy this product from Best Computer Hub Ltd. The latest price of HPE Aruba Networking 580EX Series Hazardous Location Access Points in Bangladesh is 0৳.

So, Order Online Or Visit your Nearest Best Computer Hub Shop to get yours at lowest price.

CertificationsWi-Fi Alliance
Bluetooth SIG
Ethernet Alliance (E0, PoE PD device, Class 6; E2, PoE PSE device, Class 3)
Class 1 Div 2
ATEX Zone 2
IECEx

Input voltageAC power interface: 110-240V (requires AP-AC-MLX power connector BT)

RegulatoryFCC/ISED
CE Marked
RED Directive 2014/53/EU
EMC Directive 2014/30/EU
Low Voltage Directive 2014/35/EU
IEC 60950-22
UL/IEC/EN 62368-1
IEC/EN60601-1-2
EN 50155
EN IEC 60079-0
EN IEC 60079-7
IEC 60079-0
IEC 60079-7
CSA C22.2 No.213-17
UL 121201
UL 50E

Wi-Fi antennaAP-585EX: Four integrated dual-band omni-directional antennas for 4×4 MIMO with peak antenna gain of 4.4 dBi in 2.4 GHz and 5.8 dBi in 5 GHz.
AP-587EX: Four integrated 90°H x 90°V dual-band directional antennas for 4×4 MIMO with peak antenna gain of 5.8 dBi in 2.4 GHz and 6.6 dBi in 5 GHz.

Connectivity, standardWi-Fi 6 (IEEE 802.11ax)

MountingOptional mounting kits available, see the ordering guide.

Power consumptionThe AP supports direct AC power and Power over Ethernet (802.3bt PoE; on port E0 only).
When both AC and PoE power sources are available, AC power takes priority over PoE.
Power sources are sold separately.

Maximum (worst-case) power consumption:
AC powered: 71W (802.3af/at*).
PoE powered (802.3bt Class 6): 49.5W (802.3af PSE only).
PoE powered (802.3bt Class 5): 35.5W (no PSE)
PoE powered (802.3at, IPM disabled): 25.5W (2 chains @ 2.4 GHz, 2 chains @ 5 GHz, no PSE).
Maximum (worst-case) power consumption in idle mode: 9.2W (PoE) or 10.8W (AC).
Maximum (worst-case) power consumption in deep-sleep mode: 3.0W (PoE) or 4.4W (AC).

NOTE: *With IPM enabled, the AP will adjust power requirements to meet requirements, and will reduce power as necessary according to the established IPM policy.

Radio coverageAP type: Outdoor Hardened, Wi-Fi 6 dual radio, 5 GHz and 2.4 GHz 802.11ax 4×4 MIMO.
5GHz radio: Four spatial stream Single User (SU) MIMO for up to 2.4Gbps wireless data rate with individual 4SS HE80 (or 2SS HE160) 802.11ax client devices, or with four 1SS or two 2SS HE80 802.11ax MU-MIMO capable client devices simultaneously.
2.4GHz radio: Four spatial stream Single User (SU) MIMO for up to 1,150Mbps wireless data rate with individual 4SS HE40 802.11ax client devices or with two 2SS HE40 802.11ax MU-MIMO capable client devices simultaneously.

WarrantyLimited lifetime warranty. See the warranty duration.

WeightAP-585EX models: 5.24 kg
AP-587EX models: 4.51 kg
AP-585EX models: 11.5 lbs
AP-587EX models: 9.9 lbs

DimensionsAP-585EX models: 32 x 32.4 x 31.3 cm (H x W x D)
AP-587EX models: 17.4 x 30.2 x 30 cm (H x W x D)
Not including mounting bracket
AP-585EX models: 9.6 x 12.6 x 12.3 in (H x W x D)
AP-587EX models: 6.9 x 5.9 x 11.8 in (H x W x D)
Not including mounting bracket
